TERMINATOR
Built for dominance
When second best isn’t an option
The Terminator isn’t just a light–it’s a force of nature. With an incredible 30,400 lux output at 50 metres and 20x ultra-wide zoom range, it delivers both raw power and crisp beams. In a class of its own, Terminator’s advanced CMY+CTO system and flat field projection ensure every beam is perfect from center to edge.
With groundbreaking optics
660W 6800K
Arc Lamp
LIGHT SOURCE
22,500
LUMENS
6800K
COLOR TEMPERATURE
2.68° – 50°
SPOT MODE
1.68° – 27°
BEAM MODE
34.5KG
WEIGHT
Light years ahead
- 660W 6800K arc lamp
- Up to 22500 lumen output at 50 meters
- Complete spectrum: CMY+CTO+15 filters for rich and vibrant color mixing
- Excellent color rendering: high CRI >90 (with enhancement filter)
- Razor sharp shutter framing: dual rotating gobo wheels for elegant shaping
- Animation wheel & frost glass
- Extremely even spot with flawless field consistency
Features
Proven tough
in any environment
180mm front lens and 1.68° narrow beam angle
20X wide zoom range from 1.68° – 50°
Bi-directional 8-facet and 4-facet prism
Weather-resistant IP65 tour-grade construction
Built for professionals
- DMX 512 and RDM control
Technical specs
Photometrics
- Light Source
660W 6800K arc lamp
- Output
30,400 lux @ 50m (1.68°)
- Luminious Flux
NA
- CRI
CRI:90
- Color Temperature
6800K ±400K
- LED Life
3,000 hours
KEY FEATURES
- PAN
540°
- TILT
270°
- Color System
CMY + CTO + Color wheel (15+open)
- Pixel Matrix
NA
- Zoom
Spot mode 2.68°-50°
Beam Mode 1.68°-27°
- Strobe
0 – 12Hz
- Dimming
0 – 100% linear dimming
- Gobo System
1 fixed gobo wheel (18 + open)
1 rotating gobo wheel (8 + open)
- Animation
1 animation wheel
- Framing System
Single blade ±35°, rotatable 180°
- Iris
NA
- Frost
Frost glass
- Prism
Bi-directional, combinable, 8-facet + 4-facet prism
CONTROL
- Protocol
DMX512/RDM
- Data Connections
3pin(or 5pin) DMX In/Out
- DMX Channel
32CH
- Display
2.0 inch TFT display
- Frequency
NA
- Built-in Programs
NA
- Pixel Control
NA
POWER
- Mains
100 – 240V，50 – 60Hz
- Power Connections
True Con In/Out
- Maximum Power Connections
Linking up to 1pcs only
- Data Connections
3pin(or 5pin) DMX In/Out
- Maximum Data Connections
Linking up to 32pcs
- Consumption
840W@230V
- Power Factor
0.96 @230V
- Ambient
-20°C – 45°C
PHYSICAL
- Dimension
447 x 322 x 820mm
- Weight
34.5kg
- IP Rating
IP65
- Cooling
Waterproof noiseless fan
- Housing
Die-cast magnesium with matte black finish
- Installation
NA
DOWNLOADS
